 Drag Struts! Many Options
Author Message
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
I have these aluminum struts that I came upon and started making dowels to press into the ends to fit into the shock mounts. The struts are 12.5 inches eye to eye and put the front end about 6 inches off the ground. I will make the dowels as they are ordered so it will be about a week until they ship out to you unless asked otherwise. I am sending 20 of them off to get anodized black tomorrow. There is also blue, red, and gold anodized colors available. I took one in to a local machine shop to get a bid to get these milled with a pattern in them. If you want a set let me know and i will give you a price. The more milled struts that are ordered at once the cheaper it gets. These can be ordered in many different options:
Raw-$35 a piece
Polished-$50 a piece
Anodized-$50 a piece
Anodized/Milled-
Polished/Milled-
Raw/Milled-

Im still trying to figure out how to upload pics....


Last edited by White Rider on Sun Jan 31, 2010 8:40 pm, edited 1 time in total.



Sun Jan 31, 2010 7:44 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
http://www.flickr.com/photos/47112933@N04/

This is only way that im seeing how to show you guys pics....I wish uploading them was easier


Sun Jan 31, 2010 8:02 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
TESTING: I made a jig tonight to put a strut in our press to try and see just how strong or weak these struts are. We put a single strut in and tried to break it.

RESULTS: It got a bit scary but at a little over 13,100 pounds the strut started to bend, then the welds broke and the strut cracked.

Im pretty sure these will be strong enough, there will be an ultralight strut where that milled pattern is plunged all the way through. We will do the some test with those to see what they will hold up to.

Link to the video: http://www.flickr.com/photos/47112933@N ... 5182380339

_________________
Raptor #873


Thu Feb 04, 2010 1:25 pm
Profile
User avatar

Joined: Sat Sep 20, 2008 6:43 pm
Posts: 32
Location: oregon
Post
is there different lengths?

_________________
LT-1340


Fri Feb 05, 2010 3:44 pm
Profile
User avatar

Joined: Sat Sep 20, 2008 6:43 pm
Posts: 32
Location: oregon
Post
is there different lengths?

_________________
LT-1340


Fri Feb 05, 2010 3:44 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
No, this is the only length availabe. I think it is a good length for raptors, puts the bike pretty low. What length were you thinking would be better?

_________________
Raptor #873


Fri Feb 05, 2010 10:02 pm
Profile
User avatar

Joined: Sat Sep 20, 2008 6:43 pm
Posts: 32
Location: oregon
Post
i was thinking of getting some for my street bike conversion

_________________
LT-1340


Wed Feb 10, 2010 6:14 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
Well let me know if I can sell you some, thanks

_________________
Raptor #873


Sat Feb 13, 2010 10:58 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
I sent 18 sets of struts off to get anodized black and then started workig on milling the pattern on them. Heres a link of what is done so far, worth a look. Im not smart enough to post pictures here

http://www.moddedraptor.com/community/s ... -sale.html

_________________
Raptor #873


Tue Feb 16, 2010 11:17 pm
Profile
User avatar

Joined: Wed Jun 03, 2009 6:24 pm
Posts: 9
Location: Oregon
Post
We did some more testing tonight, first we made a new jig to make sure that it didnt cause the strut to fail. We tested the ultralight version and re-tested the solid version.
RESULTS:
Ultralight - At 7,900 pounds the strut bent
Solid - At 15,000 pounds the strut bent

Video - http://www.flickr.com/photos/47112933@N04/4378371916/

_________________
Raptor #873


Sun Feb 21, 2010 10:03 pm
Profile

Joined: Mon Jul 12, 2010 10:28 am
Posts: 1
Post
I am interested in purchasing your strut set up for my yfz450. How do i go about placing an order.


Mon Jul 12, 2010 11:54 am
